Brand: Rego-Fix

Rego-Fix GM20414011653 BT40 x ER16 x 100mm H Form B Collet Chuck

SKU: FTS-GM20414011653
MPN: 4140.11653

$327.90
Unit price per

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*This is a Berkshire eSupply item*
Please note, Berkshire has many challenges with delivery dates, discontinued items, etc. Unfortunately, this is beyond our control and we cannot be held responsible for such. Any and all cancelled orders due to circumstances beyond Freers control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

Rego-Fix 4140.11653 BT40 x ER16 x 100mm H Form B Collet Chuck

Full Description

Shank Size (SS)	#40	Style	B
Connection Size (CSI)	#16	Coolant Supply Property (CSP)	Coolant Thru
Body Diameter (BD)	1.110"	Type	ER
Protruding Length (LPR)	100 mm	Measurement Type	Metric
Body Length Maximum (LBX)	3.93"	Nut Diameter	28 mm
Flange Diameter (DF)	1.11"	Length Group	Standard
Shank Type	BT

• Case hardened to 58–62 HRc • Pre-balanced to G2.5 @ 22,000 RPM's • T.I.R. from the collet cavity to the holder taper 0.0001" or better • Lot Numbers for lot traceability • Through the spindle coolant or through the flange version available • BT & CAT+ have Hi-Q clamping nut included • AT3 or beter tapers guaranteed • Superior surface finish at 0.25Ra for better fit and accuracy • Swiss made to ISO 90001 • Big Plus System - Licensed by Big Daishowa
