Brand: DESTACO

DESTACO RPW-500M-1 2 JAW WIDE BODY PARALLEL GRIPPER

SKU: DE-STA-CO-RPW-500M-1
MPN: RPW-500M-1

$1,797.17
Unit price per

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

Short Description

The DESTACO RPW-500M-1 2 JAW WIDE BODY PARALLEL GRIPPER is perfect for handling large parts with its long finger grip design. Its rack and pinion synchronizer ensures smooth and precise operation, while the rugged design guarantees a long lifespan. Experience exceptional jaw support, high grip forces, and impressive accuracy and precision with this product. With a maximum metric grip force of 667N (150lbsf), 1.500mm (1.500") stroke, 31.8mm (1.25") cylinder bore, and pressure range of 40-100 psi, the RPW is a reliable and powerful tool for any job.

*In-stock Destaco products will be shipped within 3 business days. If product doesn't show an in-stock quantity, then average lead times may vary from 2 to 12 weeks, in some cases longer.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

Full Description

DESTACO RPW-500M-1 2 JAW WIDE BODY PARALLEL GRIPPER

The RPW is designed for handling large size parts that require long finger grip designs. The rack and pinion synchronizer delivers smooth and accurate operation while the rugged design provides long operation life.

Excellent jaw support throughout the full body of the gripper
High grip forces
High accuracy and repeatibality

Product	Metric
Grip Force (N)	667
Grip Force (lbsf)	150
Stroke (mm)	38.1
Stroke (in)	1.500
Cylinder Bore (mm)	31.8
Cylinder Bore (in)	1.25
Pressure Range (psi)	40-100 psi
Temp Range Standard	-35‚° to 80‚°C (-30‚° to 180‚°F)
Temp Range Viton	-30‚° to 150‚°C (-20‚° to 300‚°F)
Actuation (Open/Closed) (Sec)	0
Accuracy (‚±mm)	0.080
Repeatability (‚±mm)	0.030
Repeatability (‚±in)	0.001
Maximum Finger Length (mm)	305
Maximum Finger Length (in)	12.00
Product Type	2 Jaw Parallel
Special Feature	Heavy Duty
Jaw Operation	Non-Synchronous Available
Weight (kg)	1.40
Weight (lb)	3.00
Product Series Description	2-Jaw Parallel Gripper
Number of Jaws	2
Product Function	Gripping
Product Family	Grippers
Product Group	Parallel Grippers
Brand	Robohand
Distributor Group	Robohand Gripping Solutions
