Brand: TMX

TMX HK313565104P Live Centers MT #4 Super Precision T.I.R. .0001

SKU: FTS-HK313565104P
MPN: 3-565-104P

$269.13
Unit price per
Save $5.88

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*Supplier Note*
Please note the delivery date may vary based on product availability which is out of our control. As such, we cannot be held accountable for these unforeseen issues. Any and all cancelled orders due to circumstances beyond Freer's control will be subject to a 4% cancellation fee that will not be waived. By checking out, you agree to these terms.

Short Description

TMX 3-565-104P Live Centers MT #4 Super Precision T.I.R. .0001

Full Description

Type	Live Center	Shank Diameter	2.5200"
Taper Type	Morse Taper	Accuracy	0.0001"
Point Style	Alloy Steel	Weight	3.85 lbs
Maximum RPM	3,000	Model No	3-565-104P
Mount	4 MT	Point Length	3.2100"
Overall Length	7.2400"	Style	Super Precision
Point Diameter	1.1000"	Maximum Workpiece Weight	1,850 lbs

Each center hardened and ground from one single piece of forging
Spindles are made of high quality alloy steel, heat treated to RC 60-62
Each live center provided with 3 selected heavy duty precision bearings
Each bearing is specifically protected against dust and coolant
