TE-CO PWS-8110 8" SINGLE STATION VISE

SKU: TC-PWS-8110
MPN: PWS-8110

$1,884.58
Unit price per
Save $10.42

Shipping calculated at checkout.

*Product images may differ from actual purchased item.*
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

*Please note, there is a $100 minimum for all Te-Co product orders*

*This product can only be purchased with a shipping account. We apologize for the inconvenience.*

Short Description

TE-CO PWS-8110 8" SINGLE STATION VISE
**Please contact Sales@freertool.com for all lead times before placing your order. Once paid for, any cancellations will have a 4% cancellation fee.**

Full Description

TE-CO PWS-8110 8" SINGLE STATION VISE

Technical Specifications:

Adds 3Ã¶ length to the collet stop
Conveniently locates long parts
Two or more tubes can be coupled for desired length
Internal thread & external thread = 1.041-24

Type	Single Station
Style	Machinable Jaws
Clamping Pressure	12,000 lb
Jaw Opening	11.000 in
Jaw Width	8.000 in
Total Length	24.470 in
Total Width	11.500 in
Total Height	5.51 in
Material	Ductile Iron
Weight	175 lb
Features	Powder coated paint resists flaking and peeling 80,000psi ductile iron body with increasednickel content for improved corrosion resistance Hardened vise bed and jaw plates Sealed and lubricated needle roller thrustbearing for maximum life and minimum torque Up to 12,000lbs. (53,379N) of clamping force Repeatability within .001Ã¶ (0.025mm) Outside rails of body are machined within0.0005Ã¶ (.013mm) square to jaw Bed height matched to size 3.310Ã¶ +/- 0.0005Ã¶(84.07mm +/- .013mm) Footprint and distance from the keyway tostationary jaw meets industry standard
